HTC Leo hardware specs, video benchmarks and new pictures

http://i17.photobucket.com/albums/b65/NyoR/SNC00012.jpg

http://i17.photobucket.com/albums/b65/NyoR/SNC00014.jpg

http://i17.photobucket.com/albums/b65/NyoR/SNC00025.jpg

Among all these rumors, most of them, were based on the existence or not of the Digital Compass and some claimed that it should have been hidden somewhere, somehow, though others supporting the idea by saying that they own final official Leo’s ROM’s that it does support. U’ll clearly see below, that through the Value Added Applications, the support of CLL.dll library, explains everything by itself, so yes, Digital Compass is there, as tested on my own, but I must say that it was part of my secrecy which now, I can’t keep it any longer.  Along with DC, its the screen chassis to fully support future WM7.

Features

Platform
Ultra slim bar type touch phone / Windows Mobile 6.5 Professional

Processor/Chipset
Qualcomm MSM 8250, 1GHz

Memory / Internal Storage
ROM: 512 MB / RAM: 320 MB / HD: 207.13MB

Display Module
4.3-inch 480×800 WVGA resolution / 65K-color / Sensitive touch screen (Capacitive) / Keep support Multi-Touch capability for WM7 Chassis
HSPA/UMTS/EDGE/GPRS/GSM Function

Internal antenna
HSPA/UMTS 2100/900 MHz and GSM/GPRS/EDGE
Quad-band (850/900/1800/1900 MHz) / HSDPA / 3GPP Release 5 compliant
Up to 7.2Mbps / HSUPA / 3GPP release 6 compliant / UE category 5, up to 2 Mbps peak rate / EGPRS Functionality / EGPRS class B / Multi-slot class 12 (10 Operator dependent) / PBCCH

Standalone GPS
Internal GPS antenna

Sensors
Motion G-sensor / Proximity sensor / Ambient Light Sensor / FM Radio

Digital Camera
Main camera: 5 MP Color CMOS with auto focus / 2x LED flash

Key/Button/Switch
Volume up and down control / Send Key / End Key (Power Key) / Windows Key / Home Key / (Cinema mode Key, TBD) / Back Key / Reset

Notification
Notification by sound, vibration, LEDs or status shown on the display
One dual colors (Green and Amber) LED in the left / lens for PDA event, battery and charging / status

Audio
Built-in microphone / Receiver / Loud speaker with hands-free support

Connectivity & Interface
Bluetooth / Version 2.1 compliant with EDR / Wi-Fi / IEEE 802.11 b/g compliant / Micro-USB: / USB 2.0 High-Speed client / 3.5 mm stereo audio jack with mic / 1.8/3V USIM/SIM card slot / microSD card slot with SDHC support

Power
Battery / Removable and chargeable battery, 1,230 mAh / AC adaptor / AC input: 100 ~ 240V AC, 50/60 Hz / DC output: 5V and 1A

Accessories (In-Box)
Quick Start Guide [Inbox] / Travel Charger, TC P300 [Inbox] / USB Sync Cable (Micro-USB to Standard USB) [Inbox] / Battery [Inbox] / Wired stereo headset with 3.5mm audio connector, HS G335 [Inbox] / Premium pouch (Carrying Case) [Inbox] / Car Charger [optional] /Car Holder with
battery cover [optional]

Microsoft Windows Mobile 6.5 Professional Applications
Microsoft Outlook Mobile / Messaging (SMS/E-mail), Contacts, Calendar,Tasks, Email Set Up Wizard / Microsoft Internet Explorer Mobile / Microsoft Media Player Mobile / Microsoft ActiveSync / Microsoft Windows Mobile Update / Internet Sharing / Pictures & Videos / Games / MSFT Zip
File Explorer / Device Management / Security Enhancement / Microsoft Office Mobile / Microsoft Windows Live! / Microsoft Smart Dial / Microsoft Remote Desktop Mobile

Value-Added Applications
Windows Mobile Enhancements / Pictures & Videos enhancements / Ring Tone enhancements Telephony (HTC) Phone Canvas(HTC) Phone Experience Multimedia / (HTC) Camera Album / MP3 Trimmer / Streaming Media Player / FM Radio / Presentation mode / Web / Push Internet / RSS HUB / YouTube Client Social Networking / Input Method EZ-INPUT / Messaging SMS/MMS Client / GPS/LBS Navigation (CoPilot, Papago) / Google Maps / Quick GPS / Support CLL.dll library for indoor positioning andreverse geo-coding / Navi-panel / Calendar to Navi / User Interface (Enhanced Manila) / TouchFLO Footprints / Auto Screen Rotation /

Tools & Utilities
HTC Common Sense / 3G to WiFi router / Task Manager / Text selection (HTC) Connection Setup / OOBE / Voice Recorder / Document Viewer / PDF / OMA DRM Engine / Java virtual machine / Long Press / End Key Confirmation (to shut down) / STK SIM manager / (HTC) Volume Control / Business Card Reader / Document Printing / Magnifier.

Video Results:

Matrix Trailers Results on Core Player 1.3.2 version

RL_XQ_640x480_1500_128.avi –> 232.99 / Video Frames: 3635
RL_MQB_320x240_512_128.avi –> 477.69 / Video Frames: 3634
RL_HQ_640x352_1024_128.avi –> 209.79 / Video Frames: 3635

Video Specs:

RL_XQ_640x480_1500_128.avi

Container

File Length Correct / OpenDML (AVI v2.0 / Interleave: 1 vid frame (42 ms), preload=522
Audio frames: Split across interleaves / Video: 26.7 MB (91.49%) / Audio: 2.30 MB (7.91%)
AVI Overhead: 181 KB (0.61%)

Audio

0x0055 MPEG-1 Layer 3/ 44100Hz 128 kb/s tot , Joint Stereo

Video

Codec: XVID / Name: XviD 1.0 RC4 (Hola) / Length: 2:31.460 / Frames: 3,635 / Kbps: 1478 / Frames: 24.000

RL_MQB_320x240_512_128.avi

Container

File Length Correct / OpenDML (AVI v2.0) / Interleave: 1 vid frame (42 ms), preload=522
Audio frames: Split across interleaves / Video: 18.4 MB (88.14%) / Audio: 2.30 MB (11.02%)
AVI Overhead: 181 KB (0.84%)

Audio

0x0055 MPEG-1 Layer 3 / 44100Hz 128 kb/s tot , Joint Stereo

Video

Codec: DX50 / Name: DivX 5.1.1 (Maupiti) / Length: 2:31.460 / Frames: 3,635 / Kbps: 1022 Frames: 24.000

RL_HQ_640x352_1024_128.avi

Container

File Length Correct / OpenDML (AVI v2.0) / Interleave: 1 vid frame (42 ms), preload=522
Audio frames: Split across interleaves / Video: 18.4 MB (88.14%) / Audio: 2.30 MB (11.02%)
AVI Overhead: 181 KB (0.84%)

Audio

0x0055 MPEG-1 Layer 3 / 44100Hz 128 kb/s tot , Joint Stereo

Video

Codec: DX50 / Name: DivX 5.1.1 (Maupiti) / Length: 2:31.460 / Frames: 3,635 / Kbps: 1022 Frames: 24.000

_Bleach_238_<7557A643>.avi (H264)

Container

File Length Correct / Multipart OpenDML AVI (2 parts), “rec list” style / (114 frames in first part, 34439 frames follow) / Interleave: 371 ms (8.9 v.frames), preload=216 / Audio frames: Aligned on interleaves

Audio

0x0055 MPEG-1 Layer 3 / 44100Hz 128 kb/s tot , Joint Stereo

Video

Codec: H264 / Name: H.264/MPEG-4 AVC / Length: 24:01.137 / Frames: 34,553 / Kbps: 861 / Frames: 23.976


Core Player Results on H264 video (under v1.3.6.Build.7427)

Average Speed : 121.58% / Video Frames: 6434 / Audio Samples: 12885846 / Amount of Data: 41463Kb / Bench Time: 03.40.723 / Bench Frame Rate: 29.150 / Bench Sample Rate: 58380 / Bench Data Rate: 1.54Mbits
